Thermostatic Mixing Valve
Model：S8100

Function
Hot and cold water entering the valve is mixed to a temperature pre-selected by the user or installer. A thermally sensitive mechanism within the valve automatically proportions the amount of hot and cold water entering to produce the required blend. The mechanism then automatically compensates for any reasonable variations in supply pressures or temperatures within the design range to maintain the pre-selected temperature.

In the event of cold water supply failure, the thermostatic mixing mechanism will automatically shut down the flow to prevent discharge of dangerously hot water. The flow will also be shut down in the event of a hot water supply failure to prevent thermal shock.

Technical data
Material Body:CW617N
Working Pressure:14bar
Working Temperature:85℃
